Custom Nursery Planting Sawtooth Plastic Film Greenhouse Single Span For Tomato

Keyword:

Low Cost Tunnel Greenhouse For Flowers Plant

Name:

Tomato Greenhouse

Material:

Plastic Film Cover

Application:

Growing Strawberry Or Tomato

Payment Terms:

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Size:

Customized

Supply Ability:

20000acres per month

Delivery Time:

20-25 work days

Packaging Details:

Package, cartons

Price:

USD12.9-24.8 per square meters

Minimum Order Quantity:

200 Sqm

Highlight:

Single Span Plastic Film Greenhouse, Tomato Plastic Film Greenhouse, Nursery Planting Plastic Film Greenhouse

Warranty:

10 Years

Product Name:

Multi-span Plastic Film Greenhouse

Inquiry

Write a Review

Custom Nursery Planting Sawtooth Plastic Film Greenhouse Single Span For Tomato

Frame structure:

(1)Hot dip galvanized steel Frame

(2) Main post: 150*150mm-100*100mm

(3) Auxiliary post : 120*60mm-100*50mm

(4) Thickness: 1-2.5mm

(5) Truss: 50*50*2.5mm

(6) Zinc coating: average 210g/㎡

(7) Gutter: thickness 2.0-2.75mm, zinc coating 275g/㎡

Covering

(1) PO/PEP/HDPE plastic film single layer film covering / double layers films one layer thickness: 120μm-200μm

(2) Polycarbonate: double/three layers

(3) Tempered glass

Single layer: 4mm/5mm

Double layer 5+6+5 mm

Can be customized according to customer requirements

Film multi-span greenhouse Parameters:

(1) Wind load: 0.55KN/㎡

(2) Snow load: 0.45KN/㎡

(3) Maximum rainfall: 140mm/h

(4) Planting bearing: 0.2KN /㎡

No.	Items	Description	Including Or Not
1	Steel Structure	Hot-galvanized steel pipe	Yes
2	Greenhouse film	There's a lot of thickness to choose from.	choose according to the clients requirements
3	Insect net	High quality polyrthylene as raw material	choose according to the clients requirements
4	Sun-shading net	Summer shade,block rain,moisture,cooling,winter spring heat preservation	choose according to the clients requirements
5	cooling system	It consists of cooling fans and cooling pad	choose according to the clients requirements
6	heating system	Hot water heating,hot air heating,electric heating	choose according to the clients requirements
7	ventilation system	Side windows and cooling fans	choose according to the clients requirements
8	Drip irrigation system	It can be customized according the greenhouse length and width	choose according to the clients requirements
9	Micro-sprinkler system	It can be customized according the greenhouse length and width	choose according to the clients requirements

Custom Nursery Planting Sawtooth Plastic Film Greenhouse Single Span For Tomato 0

Sichuan Aixiang Technology Co.,

ltd is located in Chengdu city, China , we are professional in variety of greenhouse , such as PC sheet greenhouse , PE Film greenhouse , and Glass greenhouse,tunnel greenhouse and solar greenhouse etc , All our products have passed ISO9001 Quality Standard, Our Main Market is Euro countries as Spain , And America countries as canada , usa, As well as Australia ..We Look foreward to establish long-term business relationship with you .
