Nursery Hydroponic Ebb Flow Grow Table Rolling Bench Seedbed For Greenhouse

Place the cultivation container (planting basket) with a mesh bottom on the tidal irrigation cultivation bed. The nutrient solution is pumped out from the nutrient solution pool by a special circulating water pump and sent to the cultivation bed. The cultivation bed is submerged to a depth of about 20-30mm. After about 10-15 minutes, the nutrient solution rises to the surface of the substrate in the cultivation container due to capillary action. At this time, the nutrient solution is discharged and flows back into the nutrient solution pool. The nutrient solution can also be pumped out when other cultivation beds need water. Tidal irrigation and nutrient film irrigation (NFT) also have equipment for adjusting the pH value of the nutrient solution and the concentration of various nutrients. However, because foreign objects such as crop branches and leaves, substrates, etc. are prone to fall into the nutrient solution during the circulation process, a filtration system needs to be added to prevent the nutrient solution from being too turbid.

1. Ebb And Flow Grow Table is water-saving and has a completely closed system cycle, which can achieve a water and fertilizer utilization rate of more than 90%;
2. The crop grows quickly, and the weekly seedling age can be at least 1 day earlier than the traditional seedling method, which improves the utilization rate of facilities;
3. It avoids the formation of water film on the plant leaves, so that the leaves receive more light and photosynthesis, and promotes transpiration to absorb more nutrients from the roots;
4. Ebb And Flow Grow Table can provide a stable moisture content in the root matrix to prevent the capillary roots from dying due to drought near the edge and bottom of the container;
5. It makes it easy to control relative humidity, keep the crop leaves dry, and reduce the use of chemicals;
6. It is very dry under the Ebb And Flow Grow Table, no weeds grow, and fungus growth can be reduced;
7. The management cost is reduced. Even if the nutrient solution is managed manually, one person can complete the irrigation of about 0.2h㎡• plug seedlings within 20-30 minutes;
8. It can be used at any time without restrictions on varieties, specifications, and time.

Specifications

Hydroponics is the way to go for those who want to get the most yield out of their light and area. Hydroponics

will provide bushier plants and faster growth. The Ebb and Flow complete growsystem floods the roots with a

nutrient solution. Ebb and Flow complete grow systems have been proven to be extremely effective over time

and require very low maintenance and are easy-to-use.

Detailed Image:

Advantages:

1. It can move left and right (movable 0.6m), and the height can be fine-adjusted (adjustable by 10 cm);

2. Anti-turning limit equipment to prevent skew caused by emphasis;

3. The maximum load capacity is 50kg/㎡;

4. Full hot-dip galvanizing process, durable;

5. The life span can reach 15-20 years;

6. Reduce irrigation waste, recycle and reuse;

7. Easy to install;

8. The system structure is reasonable;

9. Less maintenance;

10. High ground utilization rate

Working Principle:

Hydroponic ebb and flow trays uses pumps and a large water reservoir to periodically flood the plant

roots with nutrients and water. An easy method is using a large plastic tote to contain the nutrient solution

with the plants sitting in a deep tray on top of the lid. The nutrient solution is pumped into the tray from

the reservoir below, and then is allowed to drain back into the reservoir.
