Tropical Multi Span Polytunnel Plastic Film Berry Greenhouse With Hydroponic System
5.0
Keyword:
Large Multi-span Plastic Greenhouse For Plants
Name:
Greenhouse Structure
Material:
Plastic Film Cover
Application:
Greenhouse Tunnel Vegetable Greenhouses For Sale
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Size:
Customized
Supply Ability:
20000acres per month
Delivery Time:
20-25 work days
Packaging Details:
Package, cartons
Price:
USD12.9-24.8 per square meters
Minimum Order Quantity:
200 Sqm
Highlight:
Multi Span Plastic Film Greenhouse, Hydroponic System Plastic Film Greenhouse, Berry Plastic Film Greenhouse
Warranty:
10 Years
Product Name:
Multi-span Plastic Film Greenhouse
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Tropical Multi Span Polytunnel Plastic Film Berry Greenhouse With Hydroponic System
Frame structure:
(1)Hot dip galvanized steel Frame
(2) Main post: 150*150mm-100*100mm
(3) Auxiliary post : 120*60mm-100*50mm
(4) Thickness: 1-2.5mm
(5) Truss: 50*50*2.5mm
(6) Zinc coating: average 210g/㎡
(7) Gutter: thickness 2.0-2.75mm, zinc coating 275g/㎡
Covering
(1) PO/PEP/HDPE plastic film single layer film covering / double layers films one layer thickness: 120μm-200μm
(2) Polycarbonate: double/three layers
(3) Tempered glass
Single layer: 4mm/5mm
Double layer 5+6+5 mm
Can be customized according to customer requirements
Can be customized according to customer requirements
Film multi-span greenhouse Parameters:
(1) Wind load: 0.55KN/㎡
(2) Snow load: 0.45KN/㎡
(3) Maximum rainfall: 140mm/h
(4) Planting bearing: 0.2KN /㎡
| No. | Items | Description | Including Or Not |
| 1 | Steel Structure | Hot-galvanized steel pipe | Yes |
| 2 | Greenhouse film | There's a lot of thickness to choose from. | choose according to the clients requirements |
| 3 | Insect net | High quality polyrthylene as raw material | choose according to the clients requirements |
| 4 | Sun-shading net | Summer shade,block rain,moisture,cooling,winter spring heat preservation | choose according to the clients requirements |
| 5 | cooling system | It consists of cooling fans and cooling pad | choose according to the clients requirements |
| 6 | heating system | Hot water heating,hot air heating,electric heating | choose according to the clients requirements |
| 7 | ventilation system | Side windows and cooling fans | choose according to the clients requirements |
| 8 | Drip irrigation system | It can be customized according the greenhouse length and width | choose according to the clients requirements |
| 9 | Micro-sprinkler system | It can be customized according the greenhouse length and width | choose according to the clients requirements |
Sichuan Aixiang Technology Co.,
![Tropical Multi Span Polytunnel Plastic Film Berry Greenhouse With Hydroponic System 5]()
ltd is located in Chengdu city, China , we are professional in variety of greenhouse , such as PC sheet greenhouse , PE Film greenhouse , and Glass greenhouse,tunnel greenhouse and solar greenhouse etc , All our products have passed ISO9001 Quality Standard, Our Main Market is Euro countries as Spain , And America countries as canada , usa, As well as Australia ..We Look foreward to establish long-term business relationship with you .
