Product Description

Poly Tunnel Plastic Film 200 Micron Multi-span Customized Agricultural Greenhouse

The advantages of multi-span greenhouses, such as high land utilization rate, high degree of indoor mechanization, low energy consumption per unit area, and uniform indoor temperature and light environment, are more suitable for the development requirements of modern facility agriculture, meet the needs of future facility agriculture to integrate high-tech development, and are also the inevitable development trend of modern mechanized agriculture. Multi-span greenhouses are greenhouses with two or more spans connected by gutters without partitions in the middle. The main structure of modern greenhouses is steel and aluminum alloy, and the covering materials can be single-layer or double-layer inflatable film, plastic film and other soft materials, or PC board, corrugated board, glass, tempered glass and other hard materials.

1. Light structure, impact resistance, good load performance, excellent thermal insulation performance, durable and beautiful.

2. PC board saves more than 40% energy than other covering materials.

1. Using all-steel frame keel as bracket, the service life is long, up to more than 15 years;

2. Strong wind and snow load resistance;

3. Welded frame, easy installation, economical and durable;

4. Multi-span design, large indoor space, high land utilization rate, suitable for large-scale planting and mechanized operation.

Frame structure:

(1)Hot dip galvanized steel Frame

(2) Main post: 150*150mm-100*100mm

(3) Auxiliary post : 120*60mm-100*50mm

(4) Thickness: 1-2.5mm

(5) Truss: 50*50*2.5mm

(6) Zinc coating: average 210g/㎡

(7) Gutter: thickness 2.0-2.75mm, zinc coating 275g/㎡

Covering

(1) PO/PEP/HDPE plastic film single layer film covering / double layers films one layer thickness: 120μm-200μm

(2) Polycarbonate: double/three layers

(3) Tempered glass

Single layer: 4mm/5mm

Double layer 5+6+5 mm

Can be customized according to customer requirements

Film multi-span greenhouse Parameters:

(1) Wind load: 0.55KN/㎡

(2) Snow load: 0.45KN/㎡

(3) Maximum rainfall: 140mm/h

(4) Planting bearing: 0.2KN /㎡

No.	Items	Description	Including Or Not
1	Steel Structure	Hot-galvanized steel pipe	Yes
2	Greenhouse film	There's a lot of thickness to choose from.	choose according to the clients requirements
3	Insect net	High quality polyrthylene as raw material	choose according to the clients requirements
4	Sun-shading net	Summer shade,block rain,moisture,cooling,winter spring heat preservation	choose according to the clients requirements
5	cooling system	It consists of cooling fans and cooling pad	choose according to the clients requirements
6	heating system	Hot water heating,hot air heating,electric heating	choose according to the clients requirements
7	ventilation system	Side windows and cooling fans	choose according to the clients requirements
8	Drip irrigation system	It can be customized according the greenhouse length and width	choose according to the clients requirements
9	Micro-sprinkler system	It can be customized according the greenhouse length and width	choose according to the clients requirements

Sichuan Aixiang Technology Co.,

ltd is located in Chengdu city, China , we are professional in variety of greenhouse , such as PC sheet greenhouse , PE Film greenhouse , and Glass greenhouse,tunnel greenhouse and solar greenhouse etc , All our products have passed ISO9001 Quality Standard, Our Main Market is Euro countries as Spain , And America countries as canada , usa, As well as Australia ..We Look foreward to establish long-term business relationship with you .
