Name: Agricultural Multi-span Polytunnel UV Plastic Film Greenhouse Kit With Shade Net
Brand: Sichuan Aixiang Agricultural Technology Co., Ltd.
SKU: Multi-span
Price: 17.90 USD
Availability: InStock

Home > products > Plastic Film Greenhouse >

Agricultural Multi-span Polytunnel UV Plastic Film Greenhouse Kit With Shade Net

Agricultural Plastic Film Greenhouse Kit

Multi-span Plastic Film Greenhouse Kit

UV Plastic Film Greenhouse Kit

Place of Origin:

China

Brand Name:

Aixiang Greenhouse

Model Number:

Multi-span

Request A Quote

Product Details

Product Name:

Multi-span Plastic Film Greenhouse

Material:

Plastic Film Cover

Application:

Greenhouse Tunnel Vegetable Greenhouses For Sale

Warranty:

10 Years

Size:

Customized

Keyword:

Multi-span Tomato Greenhouse For Fruits/vegetables

Name:

Agricultural Greenhouses

Payment & Shipping Terms

Minimum Order Quantity

200 Sqm

Price

USD12.9-24.8 per square meters

Packaging Details

Package, cartons

Delivery Time

20-25 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

20000acres per month

Economical Low Cost Plastic Film Single-span Poly Tunnel Galvanized Greenhouse Tent

Get Best Price

Video

Single-Span Sawtooth Design Tropical Plastic Film Greenhouse Tunnel Customized for Vegetable Growing

Get Best Price

Video

Hot Galvanized Steel Structure Multi-Span Plastic Film Custom Greenhouse with Tropical Top Ventilation Sawtooth Design

Get Best Price

Video

Chinese Plastic Film Greenhouse For Large Area Farming Growing

Get Best Price

+8613982313279

sales04@axgreenhouse.com

86--28-68745748

Contact Now

Product Description

Agricultural Multi-span Polytunnel UV Plastic Film Greenhouse Kit With Shade Net

Film greenhouses can be used for seedling greenhouses, winter vegetable planting, summer shading, waterproofing and rain protection, rice seedlings, winter breeding and protection of livestock and poultry, planting of flowers, fruit trees, Chinese medicine, etc., yurts, milk stations, resorts, etc., as well as the production of hundreds of commodities such as cold greenhouses, mushroom sheds, breeding sheds, construction sheds, car storage sheds, warehouses, small workshops, mobile rooms, etc.

1. When covering the film, the bracket should keep its surface smooth. Tie-down measures should be taken at the support joints to prevent the film cover device from being lost.
2. Pay attention to the protective film in certain corners or places that need to be fixed
3. Try to use films of the same degree of new and old to prevent the old film from corroding the new film.
4. Be careful to roll up the film when ventilating.
5. Pay attention to the garbage on the greenhouse to prevent sharp objects from scratching the film.
6. In summer, especially in this hot season. Make a layer of sunscreen film. If the bracket is made of metal, pay more attention to the damage to the film caused by the metal temperature.
7. Make an antifreeze film in winter. The lower greenhouse makes the film easy to break.
8. If there are small cracks or holes on the film, don't be indifferent and repair it in time. Avoid large cracks.
9. When cleaning the film, use a soft brush as much as possible. The water pressure should not be too high. Clean each area one by one.
If the film is loose, it should be tightened in time. Loose film is easy to break under strong winds.

Frame structure:

(1)Hot dip galvanized steel Frame

(2) Main post: 150*150mm-100*100mm

(3) Auxiliary post : 120*60mm-100*50mm

(4) Thickness: 1-2.5mm

(5) Truss: 50*50*2.5mm

(6) Zinc coating: average 210g/㎡

(7) Gutter: thickness 2.0-2.75mm, zinc coating 275g/㎡

Covering

(1) PO/PEP/HDPE plastic film single layer film covering / double layers films one layer thickness: 120μm-200μm

(2) Polycarbonate: double/three layers

(3) Tempered glass

Single layer: 4mm/5mm

Double layer 5+6+5 mm

Can be customized according to customer requirements

Film multi-span greenhouse Parameters:

(1) Wind load: 0.55KN/㎡

(2) Snow load: 0.45KN/㎡

(3) Maximum rainfall: 140mm/h

(4) Planting bearing: 0.2KN /㎡

No.	Items	Description	Including Or Not
1	Steel Structure	Hot-galvanized steel pipe	Yes
2	Greenhouse film	There's a lot of thickness to choose from.	choose according to the clients requirements
3	Insect net	High quality polyrthylene as raw material	choose according to the clients requirements
4	Sun-shading net	Summer shade,block rain,moisture,cooling,winter spring heat preservation	choose according to the clients requirements
5	cooling system	It consists of cooling fans and cooling pad	choose according to the clients requirements
6	heating system	Hot water heating,hot air heating,electric heating	choose according to the clients requirements
7	ventilation system	Side windows and cooling fans	choose according to the clients requirements
8	Drip irrigation system	It can be customized according the greenhouse length and width	choose according to the clients requirements
9	Micro-sprinkler system	It can be customized according the greenhouse length and width	choose according to the clients requirements

Sichuan Aixiang Technology Co.,

ltd is located in Chengdu city, China , we are professional in variety of greenhouse , such as PC sheet greenhouse , PE Film greenhouse , and Glass greenhouse,tunnel greenhouse and solar greenhouse etc , All our products have passed ISO9001 Quality Standard, Our Main Market is Euro countries as Spain , And America countries as canada , usa, As well as Australia ..We Look foreward to establish long-term business relationship with you .
